O RDERING I NFORMATION
TYPE
CUB5
Optional Plug-in Cards
Accessories
MODEL NO.
CUB5P
CUB5RLY
CUB5SNK
CUB5COM
CUB5USB
MLPS
CBLPROG
CBPRO
SFCRD
CBLUSB
DESCRIPTION
Process Meter with Reflective Display
Process Meter with Backlight Display
Single Relay Option Card
Dual Sinking Open Collector Output Card
RS485 Serial Communications Card
RS232 Serial Communications Card
USB Programming Card
+12 VDC Micro-Line Power Supply, 85 to 250 VAC source, 400 mA max out
+24 VDC Micro-Line Power Supply, 85 to 250 VAC source, 200 mA max out
Programming Cable RS232 (RJ11-DB9)
Programming Cable RS485 (RJ11-DB9)
Crimson PC Configuration Software, Free Download Available 1
USB Programming Cable
PART NUMBER
CUB5PR00
CUB5PB00
CUB5RLY0
CUB5SNK0
CUB5COM1
CUB5COM2
CUB5USB0
MLPS1000
MLPS2000
CBLPROG0
CBPRO007
SFCRD200
CBLUSB00
1 Crimson
software is a free download from http://www.redlion.net. System requirements for the software are listed on the download page.
G ENERAL M ETER S PECIFICATIONS
1. DISPLAY : 5 digit LCD 0.48" (12.2 mm) high digits
CUB5PR00 : Reflective LCD with full viewing angle
CUB5PB00 : Transmissive LCD with selectable red or green LED backlight,
viewing angle optimized. Display color change capability with output state
when using an output module.
2. POWER : Input voltage range is +9 to +28 VDC with short circuit and input
10. MEMORY : Nonvolatile E 2 PROM memory retains all programming
parameters and max/min values when power is removed.
11 . ENVIRONMENTAL CONDITIONS :
Operating Temperature Range for CUB5PR00 : -35 to 75 °C
Operating Temperature Range for CUB5PB00 depends on display color
and intensity level as per below :
polarity protection. Must use an RLC model MLPS or an NEC Class 2 or
INTENSITY LEVEL
TEMPERATURE
Limited Power Source (LPS) rated power supply.
Red Display
1&2
-35
to
75
°C
MODEL
NO.
DISPLAY COLOR
INPUT CURRENT
@ 9 VDC WITHOUT
CUB5RLY0
INPUT CURRENT
@ 9 VDC WITH
CUB5RLY0
3
4
5
-35
-35
-35
to
to
to
70
60
50
°C
°C
°C
CUB5PR00
CUB5PB00
CUB5PB00
---
Red (max intensity)
Green (max intensity)
10 mA
85 mA
95 mA
40 mA
115 mA
125 mA
Green Display
1&2
3
4
5
-35
-35
-35
-35
to
to
to
to
75
65
50
35
°C
°C
°C
°C
3. INPUT RANGES : Jumper Selectable
0 to 10 V, 0(4) to 20 mA, 0 to 50 mA
4. SENSOR INPUTS:
Storage Temperature : -35 to 85 °C
Operating and Storage Humidity : 0 to 85% max. relative humidity (non-
condensing)
INPUT
RANGE
ACCURACY
@23 °C, less
than 85% RH
INPUT
IMPEDANCE
MAX INPUT
SIGNAL
RESOLUTION
TEMP.
COEFFICIENT
Vibration to IEC 68-2-6 : Operational 5-500 Hz, 5 g
Shock to IEC 68-2-27 : Operational 30 g
Altitude : Up to 2000 meters
20 / 50 mA 0.1% of span
10 ?
150 mA
1 μ A
70 ppm / °C
12. CERTIFICATIONS AND COMPLIANCES :
10 VDC
0.1% of span
538 K ?
30 V
1 mV
70 ppm / °C
CE Approved
5. OVERRANGE RATINGS, PROTECTION & INDICATION:
9 to 28 VDC power circuit is not isolated from the signal circuit.
Input Overrange Indication : “ OLOL ”.
Input Underrange Indication : “ ULUL ”.
Display Overrange/Underrange Indication : “ ..... ”/“- ..... ”
6. RESPONSE TIME :
Display : 500 msec min.
Output : 800 msec max (with input filter setting of 0)
7. NORMAL MODE REJECTION : 60 dB 50/60 Hz
8. USER INPUT (USR) : Programmable input. Connect USR terminal to USR
COMM to activate function. Internal 10K ? pull-up resistor to +9 to 28 VDC.
Threshold Levels : V IL = 0.7 V max; V IH = 2.4 V min; V MAX = 28 VDC
Response Time : 5 msec typ.; 50 msec debounce (activation and release)
9. CONNECTIONS : Wire clamping screw terminals
Wire Strip Length : 0.3" (7.5 mm)
Wire Gage : 30-14 AWG copper wire
Torque : 5 inch-lbs (0.565 N-m) max.
2
EN 61326-1 Immunity to Industrial Locations
Emission EN 55011 Class A
IEC/EN 61010-1
UL Recognized Component: File #E179259
UL Listed: File #E137808
Type 4X Enclosure rating (Face only)
IP65 Enclosure rating (Face only)
IP20 Enclosure rating (Rear of unit)
Refer to EMC Installation Guidelines section of the bulletin for additional
information.
13. CONSTRUCTION : This unit is rated for NEMA 4X/IP65 requirements for
outdoor use. Installation Category I, Pollution Degree 2. High impact plastic
case with clear viewing window. Panel gasket and mounting clip included.
14. WEIGHT : 3.2 oz (100 g)
